Extra 300LT - General

CHAPTER 96
PAGE 3
MAINTENANCE MANUAL EXTRA 300LT
PAGE DATE: 21. March 2014
96-00-00 GENERAL
Description
On pilot's demand the smoke system produces a trail of
smoke by injection of smoke oil (straight paraffin oil) into
the engine exhaust. The smoke oil is vaporised by the exhaust
gas heat and is visible as dense smoke after leaving the
exhaust.
From SN LT011 the smoke system has been changed. The
smoke acro tank and the smoke tank drain have been placed
in the middle of the aircraft (refer to Figure 1, Sheet 2).
The system consists of (refer to Figure 1):
Main smoke oil tank (1)
Smoke oil acro tank (7)
Ventilation lines (9)
Overpressure/check valve in smoke oil supply line to the
nozzle (3)
Refill/Injection pump (2)
Two relais (changeover contact type) for pump control (15)
Smoke switch (ON-OFF type) on the throttle lever (13)
SMOKE REFILL switch in the instrument panel (11)
SMOKE ARM switch in the instrument panel (12)
SMOKE SYSTEM circuit breaker in the instrument panel
(14)
Float switch (10)
Filter element in the refill line (4)
Smoke tank drain (5)
Quick connector in the bottom fuselage cover (6)
Injector nozzle (8)
