CHAPTER 31
PAGE 12
PAGE DATE: 24. February 2017
MAINTENANCE MANUAL EXTRA 300LT
31-10-06 Front Instrument Panel Support
(for Garmin G5)
In the case a Garmin G5 is installed the front instrument
panel is attached to a support, which is directly connected
to the fuselage.
Removal/Installation
1 Remove the main fuselage cover as per Chapter 53.
2 Remove the front instrument panel as per Chapter 31-10-
04.
3 Hoist the aircraft front by means of both engine hoisting
points just enough to relieve the bolts (5 and 6, Figure 7).
Refer to Chapter 07-20-01.
4 Loosen the cutout bridge attachment bolts (5) on each
fuselage side. Turn maximum 2 rotations.
5 Remove DIN 912 M12x220 bolts (6).
6 Remove front instrument panel support (1).
N O T I C E Damage to the fuselage steel tube frame can occur.
Do not lower the aircraft front before all bolts (5 & 6)
are reinstalled.
7 Reverse procedure for installation.
