CHAPTER 33
PAGE 11
PAGE DATE: 21. March 2014
MAINTENANCE MANUAL EXTRA 300LT
33-40-30 LED Landing Light System
Refer to Figure 4. Alternatively a LED landing light (1)
consisting of a hood (9), a glass (10) and a head lamp (8) is
integrated in the RH bottom half of the engine cowling. The
electrical wiring (4) connecting the LED landing light is
fastened with cable straps (5) and cable retainers to the
bottom half of the engine cowling. It features a plug-and-
socket connection on each side (2, 3).
N O T E When the cowling shall be removed the plug (3) must
be disconnected.
The system is controlled by the LANDING LIGHT switch
and is protected by the LANDING LIGHT circuit breaker
both located on the rear instrument panel (see Chapter 31-
10-00).
33-40-31 LED Landing Light
Removal/Installation
1 BATTERY switch OFF.
2 Remove engine cowlings as per Chapter 71.
3 Disconnect the plug (2, Figure 4) from the LED head lamp
(8).
4 Remove the attachment bolts (6) and remove the hood (9)
and the glass (10) which is located under the hood.
5 Install in reverse sequence of removal.
33-40-32 LED Head Lamp
Removal/Installation
1 Remove landing light as per Chapter 33-40-31.
2 Remove the attachment bolts (7, Figure 4).
3 Remove the LED head lamp (8) from the hood (9).
4 Install in reverse sequence of removal.
