Extra 300LT - Distribution Bowden Cable

CHAPTER 21
PAGE 8
PAGE DATE: 7. July 2010
MAINTENANCE MANUAL EXTRA 300LT
NOTE Ensure distance of cable housing end to clamp sheet is
50 mm (refer to detail C of figure 3) when installing
the clamp sheets.
11 Install the clamp sheets (12, 15).
12 Fasten the hose clamp (11).
13 Ensure inlet box actuator is in closed position.
14 Push main handle (1) to the full forward position. Then pull
aft 5 mm (refer to detail A of figure 3).
15 Install the Bowden cable to the inlet box actuator (14).
16 Check full travel.
Rigging
Refer to figure 3.
1 Loosen Bowden cable attachment bolt on the inlet box
actuator (14).
2 Place inlet box actuator to the closed position.
3 Adjust main handle (1) to the full forward minus 5 mm
position (refer to detail A of figure 1).
4 Fasten Bowden cable attachment bolt on the inlet box
actuator (14).
5 Check full travel.
21-40-04 Distribution Bowden Cable
Refer to chapter 20 for general information about handling
of control cables.
Removal
Refer to figure 3.
1 Remove main and bottom fuselage cover as per chapter 53.
2 Disconnect Bowden cable from the distribution box actuator
(10).
