CHAPTER 20
PAGE 8
PAGE DATE: 12. June 2015
MAINTENANCE MANUAL EXTRA 300LT
20-10-04 Special Torque Values
Special torque values for the following items must be adhered
to:
Item
Torque value
(Nm) (in.lbs)
Brake Back Plate Bolts (Cleveland)
Refer to Cleveland
Maintenance Manual
Wheel Assembly Bolts (Cleveland)
Engine Mounting
(Bolts AN7-50A / Metal Stop Nut
AN 363C-720 or MS 21046 C7)
55 480
Engine Mount to Fuselage
(Bolt Din 912, M12-12.9 / Stop Nut
DIN 985, M12-8-B2C)
80 720
Longeron Cutout Bridge
(Bolt DIN 912 M8-8.8 / Stop Nut
LN 9348-08)
18 160
Horizontal Stabilizer Front Spar Bolts
(Bolt LN 9037-10054 / Stop Nut LN
9348-10)
33 292
Horizontal Stabilizer Rear Spar Bolts
(Bolt LN 9037-10046 / Stop Nut LN
9348-10)
33 292
Vertical Stabilizer Rear Spar Bolt
(Bolt LN 9037-10065 / Stop Nut LN
9348-10)
38 336
Wing Main Spar Safety-Bolts
Drain Valve Nut
(Bolt LN 9038 K-08020)
(VD 82-2577)
15
11
10
133
100
89
Torque for Engine
Refer to Lycoming
Overhaul Manual
Torque for Propeller
Refer to
MT-propeller
Installation Manual
E-124
Top Half of the Main Landing Gear
Mounting Clamp
(Bolt )LN9037-10054
To Next Page
