Extra 300LT - Main Fuselage Cover

CHAPTER 53
PAGE 8
PAGE DATE: 24. February 2017
MAINTENANCE MANUAL EXTRA 300LT
22 Sand down (using Scotch Brite Handpad Fine) the over-
lapping part between canopy glass and canopy frame on the
inside (Area B in Figure 5).
23 Apply primer (Glasurit 934-0)(refer to Chapter 51-30) and
refinish the area.
53-00-03 Main Fuselage Cover
Removal/Installation
1 Remove the canopy per chapter 53-00-01.
2 Remove the front instrument panel per Chapter 31-10-03/
31-10-05.
3 Remove the rear instrument cover per Chapter 31.
4 Remove the rear canopy hinge.
5 Remove the filler neck attachment screws.
6 Remove the main fuselage cover attachment screws.
7 Remove the main fuselage cover.
8 Install in reverse sequence of removal. Perform pitot-static
system test.
