CHAPTER 31
PAGE 4
PAGE DATE: 7. July 2010
MAINTENANCE MANUAL EXTRA 300LT
31-10-00 INSTRUMENT AND CONTROL PANELS
31-10-01 Rear Instrument Panel
The instrument panel of the rear cockpit consist of a top
panel sheet (instrument panel) with an instrument cover and
a center panel sheet (control switch and circuit breaker
panel). When the MVP-50 is installed generally an additional
sub-panel is installed (refer to Chapter 77-40-00).
The panels and the cover are mounted on the steel frame with
AN 526 C 1032 R8 bolts.
For the standard panel arrangement of the rear cockpit refer
to Figure 1 and 2 and the adjacent charts.
N O T E The charts may be modified by the minimum equipment
requirements of individual certifiying authorities.
