CHAPTER 77
PAGE 9
MAINTENANCE MANUAL EXTRA 300LT
PAGE DATE: 7. July 2010
77-40-00 INTEGRATED ENGINE INSTRUMENT
SYSTEMS
77-41-00 Electronics International MVP-50P
The EXTRA 300 LT can be equipped with the MVP-50P
Glass Panel Engine Monitor. The complete system as
installed in the EXTRA 300LT consists of:
Item Location
Main Engine Screen Rear instrument panel
Electronic Data Converter Mounting sheet
Resistive Level Fuel Module Mounting sheet
Fuel Quantity Transducers* Wing root ribs
Manifold Pressure Transducer Mounting sheet
Oil Pressure Transducer Firewall
Fuel Pressure Transducer Firewall
Fuel Flow Transducer Left side engine
OAT Probe Bottom fuselage cover
Oil Temperature Sensor Aft engine
EGT Probes Exhaust pipes
CHT Probes Cylinder heads
Related Wiring and Tubing Cockpit/engine comp.
*) An additional fuel quantity transducer identical to the
standard one is installed in the RH wing, when the MVP-50P
is used.
N O T E Apart from the different probes and transducers used
with the MVP-50P the engine installation including the
wet lines is the same as described in the standard
configuration description.
