CHAPTER 96
PAGE 7
MAINTENANCE MANUAL EXTRA 300LT
PAGE DATE: 21. March 2014
96-10-02 Smoke Oil Acro Tank
Removal/Installation
1 Remove canopy, main fuselage cover, instrument cover as
per Chapter 51 and the front seat as per Chapter 25.
2 Drain the smoke system.
3 Loosen the center fuel tank and move to the RH side.
4 Remove the battery as per Chapter 24.
5 Disconnect the smoke oil lines from the smoke oil acro
tank.
C A U T I O N Prevent the drain tube of the GRP tank shell from
breaking when handling the smoke oil acro tank.
6 Remove the metal attachment belts with the rubber stripes.
7 Remove the smoke tank through the cockpit.
8 Install in reverse sequence of removal.
