Extra 300LT - Rudder

CHAPTER 27
PAGE 19
PAGE DATE: 21. March 2014
MAINTENANCE MANUAL EXTRA 300LT
27-20-01 Rudder
I M P O R T A N T Perform checks 10-12 of "Flight Controls" presented
in Chapter 05-20-04 after each maintenance work af-
fecting the rudder control cables.
Removal/Installation
1 Disconnect the rudder control cables from the bottom hinge
bellcrank.
2 Loosen the hinge bolts and the ground bonding leads and
remove the bolts.
3 Install in reverse sequence of removal. Observe the second
note of Chapter 27-00-00.
Rigging
N O T E Inspect the control cables, the pulleys, the fairleads and
the bottom hinge assembly (with the travel stop plate)
for signs of wear or damage before beginning any ad-
justments. Replace parts if necessary.
1 Secure the rudder pedals in neutral position.
2 Check if the rudder is in 0°-position. (Rudder horn leading
edge in alignment with the leading edge of the vertical
stabilizer.)
3 Replace the control cables and adjust the length as per Chap-
ter 27-20-04 if necessary.
4 Check if the rudder travel is within the given tolerances (left/
right 30° ±2°).
5 If the rudder travel is out of limits, contact the manufac-
turer for advice.
