Extra 300LT - Throttle Control Cable

CHAPTER 73
PAGE 4
MAINTENANCE MANUAL EXTRA 300LT
PAGE DATE: 12. June 2015
73-20-11 Throttle Control Cable
Refer to Chapter 20 for general information about handling
of control cables.
Removal
1 Ensure master switch is off.
2 Remove engine cowling per Chapter 71.
3 Remove main fuselage cover per Chapter 53.
4 Remove cotter pin, castle nut, washers and bolt from the
rod end (2, Figure 4) to throttle actuator (1) attachment.
5 Loosen counter nut and remove the rod end from the throttle
control cable.
6 Remove rod end counter nut and throttle control cable
protective swivel and wiper seal.
7 Remove clamp block (3) attachment bolt(s).
8 Remove clamp block from the throttle control cable.
9 Remove cushioned clamp (4).
10 Cut safety wires and remove fire sleeve from the throttle
control cable.
11 Remove 4 bolts and firewall sealant of the clamp sheets
(Figure 2) positioned at the firewall break through.
12 Mark throttle control cable routing and positions of the cable
ties and remove the cable ties in the cabin area.
13 Remove cotter pin, castle nut, washers and bolt and remove
the rod end (6, Figure 3) from the throttle control lever (5).
14 Loosen counter nut and remove the rod end from the throttle
control cable.
15 Remove rod end counter nut and throttle control cable
protective swivel and wiper seal.
16 Remove clamp block (4) attachment bolt(s).
17 Remove clamp block from the throttle control cable (8).
18 Pull complete throttle control cable aft to remove from
aircraft. Secure clamp sheets.
