CHAPTER 28
PAGE 8
PAGE DATE: 12. June 2015
MAINTENANCE MANUAL EXTRA 300LT
28-10-01 Center Tank
Removal/Installation
1 Remove the main fuselage cover (refer to chapter 53-00-
03).
2 Remove the front seat as per chapter 25-10-01.
3 Remove wing as per chapter 57-00-01.
4 Drain the fuel system as per chapter 12-10-02.
5 Loosen the electrical bonding, the fuel quantity transducer
wiring and the hose fixtures.
6 Loosen and remove the metal attachment belts including the
rubber strips.
7 Remove the center tank.
8 Install in reverse sequence of removal.
28-10-02 Acro Tank
Removal/Installation
1 Remove the main fuselage cover and the bottom fuselage
cover as per chapter 53-00-03 & 53-00-04, respectively.
2 Remove the front seat as per chapter 25-10-01.
3 Drain the fuel system as per chapter 12-10-02.
4 Loosen the electrical bonding and the hose fixtures.
5 Loosen and remove the metal attachment belts including the
rubber strips.
6 Remove the acro tank.
7 Install in reverse sequence of removal.
