CHAPTER 73
PAGE 18
MAINTENANCE MANUAL EXTRA 300LT
PAGE DATE: 12. June 2015
73-30-11 Fuel Pressure Gauge
Removal/Installation
Refer to Chapter 31.
73-30-12 Sense Line
Removal/Installation
1 Remove cowling per Chapter 71.
2 Remove clamps.
N O T I C E Pick up spilling fluid, when disconnecting a sense line.
3 Disconnect the sense line from the fitting.
4 Remove the sense line.
5 Install in reverse sequence of removal. Torque sense line
fittings with 15.3 – 16.9Nm (135-150lbs-inch) and apply
inspection lacquer.
73-30-15 Fitting
Removal/Installation
1 Remove cowling per Chapter 71:
2 Disconnect the sense line as per Chapter 73-30-12.
3 Remove the fitting.
4 Install in reverse sequence of removal.
