CHAPTER 77
PAGE 13
MAINTENANCE MANUAL EXTRA 300LT
PAGE DATE: 24. February 2017
77-41-02 Mounting Sheet
To carry the electronic data converter (1, Figure 5) and two
modules (2 - 3) a mounting sheet (10) is installed on the right
side of the fuselage just behind the firewall.
Removal/Installation
1 Remove main fuselage cover as per Chapter 53.
2 Remove the electronic data converter (1, Figure 5) and the
modules (2 - 3) as per following sections.
3 Remove the attachment bolts and shock mounts (9) and
remove the mounting sheet (10).
4 Reverse procedure for installation.
77-41-03 Electronic Data Converter
Removal/Installation
1 Remove main fuselage cover as per Chapter 53.
2 Disconnect the electrical wiring (8) from the electronic data
converter (1, Figure 5).
3 Remove the attachment bolts (11) and remove the electronic
data converter (1).
4 Reverse procedure for installation.
77-41-04 Module
Removal/Installation
1 Remove main fuselage cover as per Chapter 53.
2 Disconnect the electrical wiring (8) and/or tubing (7) from
the module (2 or 3, Figure 5).
3 Remove the attachment bolts (12) and remove the module
(2 or 3).
4 Reverse procedure for installation.
