CHAPTER 61
PAGE 7
SERVICE MANUAL EXTRA 300LT
PAGE DATE: 12. June 2015
61-20-01 Governor
One of the following governors is installed:
MT-Propeller P-880-5, preset for a max. 2700 rpm
Woodward A-210988, preset for a max. 2700 rpm
Refer to the MT-Propeller Operation- and Installation Manual
E-1048 for further information.
NOTE The lever position of the governor actuator is preset.
Do not change this position.
61-20-02 RPM Vernier Control Cable
Refer to chapter 20 for general information about handling
of control cables.
Removal
1 Ensure master switch is off.
2 Remove engine upper cowling per Chapter 71.
3 Remove main and bottom fuselage cover per Chapter 53.
4 Remove cotter pin, castle nut, washers and bolt from the
rod end (1, Figure 2) to governor actuator (2) attachment.
5 Loosen counter nut and remove the rod end (1) from the
vernier control cable (6).
6 Remove rod end counter nut and vernier control cable
protective swivel and wiper seal (4).
7 Remove clamp block (5) attachment bolt(s).
8 Remove clamp block from the vernier control cable (6).
9 Remove 2 bolts of the clamp sheet attachment positioned
at the rear engine baffle break through (11). Disconnect both
clamp sheets and contained plastic guidance from the engine
baffle.
