CHAPTER 25
PAGE 3
PAGE DATE: 21. March 2014
MAINTENANCE MANUAL EXTRA 300LT
25-10-00 FLIGHT COMPARTMENTS
The EXTRA 300LT is standard equipped with a pilot and a co-
pilot seat including special aerobatic seat belt/shoulder
harnesses for both seats. An aircraft document bag is installed
in the rear cockpit.
25-10-01 Front Seat
The front seat is a nonadjustable one-piece composite de-
sign. It is connected to the fuselage by four screws at the top
of the backrest and by two screws at each seat-to-pedal
connection.
Removal/Installation
1 Remove rear instrument cover as per Chapter 31.
2 Loosen the leather protection cuff from the control stick.
3 Remove front seat attachment screws.
4 Remove front seat.
5 Disconnect crotch strap from seat if necessary.
6 Install in reverse sequence of removal.
25-10-02 Rear Seat
The rear seat assembly consists of two parts. The seat and the
backrest are composite materials which are connected by
bolts to a separate steel frame resp. steel tubes which allow
adjustment. The front of the seat is connected to the fuselage
by bolts. The seat to backrest connection and the connections
to the fuselage are made by means of quickpins.
