CHAPTER 53
PAGE 2
PAGE DATE: 24. February 2017
MAINTENANCE MANUAL EXTRA 300LT
Chapter 53
53-00-00 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Figure 1 Fuselage Steel Tube Design . . . . . . . . . . . . . . . . . . . . . 4
53-00-01 Canopy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
53-00-02 Canopy Glass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 2 Typical Cross Section of Canopy Bonding Area . . . . . 5
Figure 3 Canopy Position Markings . . . . . . . . . . . . . . . . . . . . . 6
Figure 4 Canopy Tape Markings . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 5 Canopy Adhesive Remainders . . . . . . . . . . . . . . . . . . . 7
53-00-03 Main Fuselage Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 6, Sheet 1 Layer Sequence Main Fuselage Cover . . . . . . . . . . . . 9
Figure 6, Sheet 2 Layer Sequence Main Fuselage Cover . . . . . . . . . . . 10
53-00-04 Bottom Fuselage Cover . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 7 Forward View on Bottom Side Firwall . . . . . . . . . . . . 11
Figure 8 Layer Sequence Bottom Fuselage Cover . . . . . . . . . . 13
Figure 9 Layer Sequence Cuffs . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 10 Layer Sequence Tail Fairing . . . . . . . . . . . . . . . . . . . 15
Figure 11 Layer Sequence Top Half of the Engine Cowling
up to SN LT040 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 12 Layer Sequence Top Half of the Engine Cowling
from SN LT041 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 13 Layer Sequence Bottom Half of the Engine Cowling
up to SN LT040 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 14 Layer Sequence Bottom Half of the Engine Cowling
from SN LT041 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table of Contents
Chapter/Figure Title
