CHAPTER 27
PAGE 7
PAGE DATE: 21. March 2014
MAINTENANCE MANUAL EXTRA 300LT
Figure 5 Control Rod Measurement
Refer to the following Figure 6 for identification of the
control rods.
0
2
1
3
4
7
8
6
Figure 6 Control Rod Identification
doRlortnoCtnemerusaeMtnemngiladnedoR
0mm0201°0
1mm908°0
2mm546°0
3mm737°0
4mm467°0
6mm235°09
7mm7801°02
8mm591°0
Table 1 Control Rod Measurement & Rod End Alignment
