CHAPTER 34
PAGE 3
PAGE DATE: 7. July 2010
MAINTENANCE MANUAL EXTRA 300LT
34-00-00 GENERAL
The Extra 300LT is equipped with an altimeter, an airspeed
indicator and a magnetic compass in the rear cockpit. In the
front cockpit an additional airspeed indicator and altimeter
are installed.
Refer to the Equipment List of the Pilot's Operating
Handbook for installed optional equipment.
The colour markings on the instruments follow US-FAR,
part 23 recommendations.
To get the pitot and static pressure a pitot/static tube is
installed at the LH wing leading edge.
IMPORTANT Perform a leakage test on the pitot/static system
whenever working on the system has been necessary.
