CHAPTER 53
PAGE 7
PAGE DATE: 7. July 2010
MAINTENANCE MANUAL EXTRA 300LT
Filler
A
B
Figure 5 Canopy Adhesive Remainders
12 Remove the fine tape.
13 Prepare adhesive (3M Scotch-Weld Urethane Adhesives
3549 B/A )(refer to chapter 51-30): Thoroughly mix approx.
300 g (approx. 10.6 oz.) adhesive (weight ratio white base :
brown accelerator - 100 : 109, 40-70 minutes application
time at RT). Mix approximately 15 seconds after a uniform
color is obtained.
14 Put adhesive on the bonding area. For maximum bonding
strength, apply product to both canopy glass and canopy
frame.
15 Place canopy glass in canopy frame. Observe correct
position using position markings.
16 Apply pressure on canopy glass using tightener to hold it in
place.
17 Remove adhesive remainders with wooden spatula.
18 Curing time: min. 75 °F 8h
68 °F 15h
19 The next day: Remove tightener and remove canopy from
form.
20 Sand down (using Scotch Brite Handpad Fine) a small area
around the outside edge between canopy frame and canopy
glass (area A in figure 5).
21 Apply primer (EP801-72, curing time: 24h) before applying
filler (Glasurit 839-53) and refinish the area (refer to
Chapter 51-30).
N O T I C E
Make sure, the filler does not get in contact with
untreated canopy glass.
