CHAPTER 21
PAGE 9
PAGE DATE: 7. July 2010
MAINTENANCE MANUAL EXTRA 300LT
3 Loosen hose clamp (13).
4 Mark distribution Bowden cable (3) routing and remove the
attachment self-clinching plastic straps (5).
5 Remove attachment nut and washer (7) of the distribution
control unit (2).
6 Pull the distribution control unit (2) with the complete
Bowden cable (3) aft to remove from aircraft. Secure label
plate (8) and attachment nut and washer (7).
Installation
Refer to figure 3.
1 Thread the Bowden cable (4) end through the respective
attachment tube (6).
2 Thread the attachment nut and washer (7) on the Bowden
cable.
3 Ensure nut (9) is fastened.
4 Place label plate (8) and align.
5 Attach the distribution control unit (1) and the label plate
(8) by means of its attachment nut and washer (7).
6 Lay the Bowden cable (3) along the prior marked routing.
7 Fasten the Bowden cable (3) with self-clinching plastic
straps (5) in place.
8 Thread the Bowden cable end through the hoseclamp (13).
NOTE Ensure distance of cable housing end to hose clamp (13)
is 40 mm (refer to detail B of figure 3) when fastening
the hose clamp.
9 Fasten the hose clamp (13).
10 Ensure distribution box actuator is in upmost position.
11 Push distribution handle (1) to the full forward position.
Then pull aft 5 mm (refer to detail A of figure 3).
12 Install the Bowden cable to the distribution box actuator
(10).
13 Check full travel.
