CHAPTER 24
PAGE 9
PAGE DATE: 21. March 2014
MAINTENANCE MANUAL EXTRA 300LT
Removal/Installation (from SN LT005)
N O T I C E Ensure the BATTERY switch is in Off-position.
1 Remove the rear instrument panel cover as per chapter 31.
2 Remove the front seat as per chapter 25.
3 Disconnect the electrical wiring from the battery.
4 Remove the 4 attachment nuts (LN9348-06) and the top at-
tachment frame.
5 Lift the battery out of its bottom frame and remove.
6 Install in reverse sequence of removal.
