CHAPTER 27
PAGE 22
PAGE DATE: 21. March 2014
MAINTENANCE MANUAL EXTRA 300LT
13 Pre-install the LN9037-06030 bolt, the DIN 125-8,4 wash-
ers (one on both sides of the thimble and one below the
tailwheel steering attachment bracket), the DIN 125-6,4
washers, the bushing, the LN9348-06 nut and the thimble
on the bottom hinge bellcrank.
14 Slip the 80 mm 771095 shrinking sleeve and a NICO-
PRESS 18-3-M or 28-3-M sleeve on the control cable end.
15 Move the cable around the thimble and stretch the control
cable with a force that is equivalent to the tractive effort of
the rear pedal retracting spring.
I M P O R T A N T Clamping has to be performed in accordance with the
Service Bulletin 300-1-93 and the Instruction No. 32 of
the National Telephone Supply Co., Cleveland Ohio.
16 Consider to let a distance of 1 mm between the thimble and
the sleeve and clamp the sleeve.
17 Cut the free end of the cable 20 mm in front of the sleeve.
18 Slip the 80 mm 771095 shrinking sleeve on the cable end
and the protective hose, center on the protective hose end
and heat up with a heat gun.
19 Slip the other 80 mm 771095 shrinking sleeve on the front
end of the protective hose, center on the protective hose
end and heat up with a heat gun.
20 Remove the pedal securing device.
21 Mount the pre-assembled shorter control cable to the front
pedal using the shackle.
22 Thread the free end of the control cable through the pulley,
the front fairleads and the pre-installed NICOPRESS
18-3-M or 28-3-M sleeves.
23 Fix the front pedal in almost vertical position (97° relative
to the footrest). Use a template as shown in Figure 16.
