CHAPTER 28
PAGE 22
PAGE DATE: 21. March 2014
MAINTENANCE MANUAL EXTRA 300LT
28-40-00 INDICATING
(Refer to figure 11) For fuel contents indicating the center
tank is equipped with a tubular fuel quantity transducer (1)
and the left wing tank with a lever-type fuel quantity transducer
(2).
If the optional MVP-50P is installed the right wing tank is
also equipped with a lever-type fuel quantity transducer
(refer to chapter 77-40).
They transmit the fuel levels to the respective fuel quantity
indicators at the instrument panel (3). In contrast to the fuel
quantity indicator of the center tank the one of the wing tank
is not adjustable. If the indication is inexact the float wire of
the tank unit has to be adjusted (refer to chapter 28-40-05).
