CHAPTER 28
PAGE 24
PAGE DATE: 7. July 2010
MAINTENANCE MANUAL EXTRA 300LT
28-40-01 Fuel Quantity Indicator
Removal/Installation
1 Disconnect battery.
2 Loosen the nuts, remove the
mounting bracket and re-
move the fuel quantity indi-
cator.
3 Disconnect the wiring (the
lamp is not used).
4 Install in reverse sequence
of removal observing the
wiring diagram.
