CHAPTER 31
PAGE 9
PAGE DATE: 24. February 2017
MAINTENANCE MANUAL EXTRA 300LT
31-10-04 Front Instrument Panel Frame
The front instrument panel is installed in frame which is
connected to the main fuselage cover.
Removal/Installation
1 Remove front instrument panel as per Chapter 31-10-03.
2 Remove the AN526 C-1032-R6 frame attachment screws
(3, Figure 5).
3 Remove the front instrument panel frame (6).
4 Reverse procedure for installation.
