CHAPTER 32
PAGE 12
PAGE DATE: 21. March 2014
MAINTENANCE MANUAL EXTRA 300LT
32-40-03 Tail Wheel
Disassembly/Assembly
Refer to figure 3.
1 Shore the tail as per chapter 07-20-02.
2 Remove the axle bolt, washers, and stopnut (10).
3 Remove the tailwheel.
4 Disassemble the bearings (11), the wheel halves (12), the
spacer sleeve (13), and the solid rubber tire (14).
5 Reverse procedure for assembly.
