MAINTENANCE MANUAL EXTRA 300LT

Style

ECC/CCC

WLB-No.*

DIN 65147

US-style

weave

patterns

weight

g/m²

twill 2/2

502

none 158

*WLB: Werkstoff Leistungsblatt, according to German

standard DIN-WL

Glass rovings

Manufacturer: GEVETEX Textilglas-GmbH

Postfach 426,

D-5100 Aachen, Germany

Supplier: Lange & Ritter GmbH

Dieselstraße 25,

D-70839 Gerlingen, Germany

Type: Vetrotex EC14 - 2400-P185

Carbon rovings

Manufacturer: Toho Tenax Europe GmbH

Kasinostr. 19-21

D-42103 Wuppertal

Type: TENAX HTS5631 1600tex f24000 t 0

(WLB: 8.3614.1)

Carbon UD-Tape

Manufacturer: J.H. Vom Baur Sohn GmbH & Co. KG

Marktstr. 34

42369 Wuppertal

Type: CF UD tape 30 mm & 50 mm

Core material

a) PVC Foam

Manufacturer: Alcan Airex AG

Industrie Nord 26

CH-5643 Sins, Switzerland
