CHAPTER 55
PAGE 6
PAGE DATE: 12. June 2015
MAINTENANCE MANUAL EXTRA 300LT
Removal
Remove elevator and rudder as per chapters 27-20-01 and
27-30-01, remove the vertical stabilizer as per chapter 55-
30-00 and then reverse the installation procedure.
Installation
N O T I C E Make shure that the trim bowden cable will not be dam-
aged when installing the horizontal stabilizer.
1 Slide the horizontal stabilizer with its front spar (1, figure 2)
into the attach brackets (4) on fuselage. The rear spar (2) is
positioned behind the rear attachment bracket (5) (trim tab
is on the right side).
2 Slide in the front spar attachment bolts (8) with an additional
washer under the bolt head from the front to the rear. These
bolts are also used for the vertical stabilizer attachment.
Therefore do not apply stop nuts before the vertical
stabilizer is fitted to the fuselage.
3 Slide in the rear spar attachment bolts (7) from front to rear.
Torque nuts for fastening.
4 Fasten the ground bonding lead (3) by means of the bolt (6),
the washers and the stop nuts.
5 Follow the procedure of Vertical Stabilizer Installation (refer
to chapter 55-30-00).
