CHAPTER 55
PAGE 10
PAGE DATE: 12. June 2015
MAINTENANCE MANUAL EXTRA 300LT
Removal
1 Remove the tail fairing and the tail cone access panel as per
chapter 51-00-01.
2 Remove the rudder as per chapter 27-20-01.
3 Remove the bottom hinge bracket assembly as per chapter
27-20-02.
4 Remove the two stop nuts (2, figure 5) and washers of the
front main bolts.
5 Remove the rear main bolt (3) with the washers and the stop
nut.
N O T I C E Do not move the fin too far backward, the antenna could
be damaged.
6 Move the fin backward and lift the fin over the antenna.
Installation
1 Put the vertical stabilizer leading edge over the antenna.
N O T I C E Do not move the fin too far backward, the antenna could
be damaged.
2 Slide the auxiliary spar attachment sheet (1, figure 5) of the
vertical stabilizer from the rear over the preinstalled
horizontal stabilizer front spar bolts and install the washers
and stop nuts (2).
3 Insert the bolt (3) to the main spar from rear to front. Use
stop nuts and washers.
4 Install the bottom hinge bracket to the tail as per chapter
27-20-02.
5 Reinstall the tail fairing, the tail side skins and the tail cone
access panel as per chapter 51-00-01.
