CHAPTER 71
PAGE 4
SERVICE MANUAL EXTRA 300LT
PAGE DATE: 24. February 2017
Removal/Installation
N O T E It is favourable to remove the cowling with two persons.
W A R N I N G Before rotating the propeller in the most convenient
position for removal of the cowling, make sure that the
ignition switch is in the “OFF” position.
1 Rotate the propeller in the most convenient position.
2 Remove the related truss head screws (4) & (5) of top
cowling half (see Figure 1).
3 Remove top half of the engine cowling.
4 Disconnect the landing light wiring using the plug shown in
Figure 2, Sheet 1 (Xenon) or Sheet 2 (LED).
5 Remove the remaining truss head screws (4) & (5) of the
bottom cowling half (see Figure 1).
6 Remove the bottom half of the cowling.
N O T I C E Pay attention to the rubber flaps of the air baffles. Make
shure they are not pushed outwards when installing the
top half of the engine cowling.
7 Install in reverse sequence of removal.
