CHAPTER 71
PAGE 11
SERVICE MANUAL EXTRA 300LT
PAGE DATE: 24. February 2017
3 Disconnect ignition harness.
4 Disconnect air ducting to exhaust heat exchanger at air intake
of forward LH baffle.
5 Unscrew grommets for ignition harness and RPM bowden
cable from their cutouts and pull out ignition harness and
RPM bowden cable.
6 Unscrew baffle plates.
Installation
Install in reverse sequence of removal.
N O T E Minor cracks in the plating can be stopped by drilling
a hole at the end of the crack. Serious damage requires
replacement of the baffle concerned.
