CHAPTER 73
PAGE 6
MAINTENANCE MANUAL EXTRA 300LT
PAGE DATE: 12. June 2015
N O T E It is essential that the rod end is screwed onto the
threaded terminal until the inspection hole of the rod
end is completely filled with thread (minimum 8 turns).
10 Screw the rod end onto the threaded terminal to match the
full idle travel stop throttle actuator position. Tighten the
counternut.
11 Install rod end to throttle actuator with bolt, washers, castle
nut and cotter pin (2, Figure 4). Tighten the castle nut slightly.
Ensure movability of actuator.
N O T E It is essential that the rod end is screwed onto the
threaded terminal until the inspection hole of the rod
end is completely filled with thread (minimum 8 turns).
12 Screw the rod end onto the threaded terminal on the throttle
control lever side of the throttle control cable.
13 Tighten the counternut to prevent rod end from loosening.
14 Install the rod end to the throttle control lever with bolt,
washers, castle nut and cotter pin (3, Figure 3). Tighten the
castle nut slightly.
15 Ensure movability of throttle control lever.
16 Perform Throttle Control Lever Rigging (refer to Chapter
73-20-12).
