Operating manual.
CNC 8060
CNC 8065
MANUAL (JOG) MODE
5.
Setting and activating the zero offsets and the fixture offsets.
·129·
(REF: 1807)
5.6 Setting and activating the zero offsets and the fixture offsets.
In jog mode, it is possible to save the active offset in the zero offset table or in the fixture offset
table (zero offset, coordinate presetting, etc.) and to activate a zero offset already defined
in the tables.
Loading a new zero offset or fixture offset into the table.
With an active offset, use the cursor to select an offset from the list and press [ENTER] to
save the current offset in that zero offset. The position of all the axes of the channel are
updated at the selected zero offset.
Applying a zero offset or fixture offset stored in the table.
Use the cursor to select a zero offset or fixture offset from the list and press the [START] key
to activate. The new zero offset is applied to all the axes of the channel.
This softkey shows the zero offsets and the fixture offsets of the system and their value in
each axis of the channel. This list is a brief information of the zero offset tables and fixture
offset tables and any change made in jog mode also affects those tables.
