12.6 Measurement
This softkey may be used to measure the distance between two points. This option is only
available for the types of graphics "XY", "XZ", "YZ" and "Solid 3D".
When selecting this option, the section being measured will appear on the graphics with two
cursors and a dashed line. The cursor currently selected will appear in red.
The dialog area will show the coordinates of both cursors, the distance between them on
the straight line and the components of that distance on the axes of the active plane. The
coordinates of the selected cursor will appear in red.
Measurement "Point1" & "Point2"
This option is used to select the cursor to be moved (same as using the [+] key).
Measurement "Edit"
This option is used to manually edit the position of the cursors. It is edited in the dialog area
of the graphic window that shows the position of both cursors.
Key. Meaning.
To move the zoom frame around.
To change the size of the zoom frame.
When selecting this option, the softkey menu shows the available options. To return to the
main menu, press the [BACK] key.
