Operating manual.
CNC 8060
CNC 8065
PLC
20.
"Messages" service
·385·
(REF: 1807)
20.13.6 Save, load and print a message and error table
Save table
To save the table data, press the "Save" softkey and the CNC will show a list with the files
saved at the CNC.
To save the table data:
1 Select the destination folder.
2 Define the file name at the bottom window. To replace an existing file, select it from the list.
3 Press [ENTER] to save the file or [ESC] to cancel the operation.
The file will be saved with the extension: *.MEF.
Load table
To recover the table data, press the "Load" softkey, the CNC will show a list with the files
available at the CNC.
To load the table data:
1 Select the folder where the file is.
2 Select the file or write its name at the bottom window.
3 Press [ENTER] to accept the selection or [ESC] to cancel it and close the file listing.
Print table
This softkey may be used to print the table of messages and errors in the pre-determined
printer or save it as a file (prn format) at the CNC. When selecting the "File" option, it will
be saved in the folder "C:\Cnc8070\Users\Reports\".
When selecting this option, the CNC will show a dialog box requesting the print destination
(printer or file). After selecting the destination, press [ENTER] to print it or [ESC] to cancel it.
