Operating manual.
CNC 8060
CNC 8065
3.
HOW TO OPERATE THE CNC
File selection window
·78·
(REF: 1807)
3.7 File selection window
The file selection window is common to all operating modes. This window is displayed when,
from an operating mode, the operator selects the option to open, save or import a file, open
or load a table, etc.
From this window, it is possible to either select an existing file or create a new one. A new
file may be created only when it is a valid action. Depending on the operating mode it is
accessed from, the list will only show the proper files.
A Type of file and operation to carry out (open, save, etc.).
B Folder tree.
C Files contained in the selected folder.
D Area to define the name of the new files. A file can also be selected when knowing its
name.
Move around in the window
Besides the mouse, the following keys may be used.
Creating a new file
To create a new file:
1 Select the destination folder for the file.
2 Write the file name at the bottom window.
3 Press [ENTER] to confirm the action.
Pressing [ESC] cancels the operation at any time and closes the window.
Key. Meaning.
It switches the window focus.
With the focus on a folder, it closes and opens the submenu
of folders.
To move the focus through the elements of the window.
To move the focus page by page.
To move the focus to the beginning or end of the list.
Opens the selected file.
To cancel the selection and close the program listing.
