Fagor CNC 8060 - Page 474

Operating manual.
CNC 8060
CNC 8065
26.
KINEMATICS CALIBRATION.
Kinematics calibration (Kinematic offsets).
·474·
(REF: 1807)
Parameters of the cycle.
Feedrate.
Safety distance and withdrawal.
Ball size.
Adjusting the probe.
Points to probe for calculating the center of the ball.
Fa Positioning feedrate
Fs Rapid probing feedrate. Then, the CNC will repeat the probing movement at
feedrate ·F·.
F Accurate probing feedrate.
Ssp The speed and turning direction for spindle orientation; the sign means the turning
direction. The CNC only offers this parameter when the spindle may be oriented
(M19), so the probe always touches the ball with the same surface.
It is up to the user to make sure that the probe can rotate without danger. If the probe has a cable,
check that the cable does not hinder the rotation of the probe.
Ds Safety distance between the probe and the calibrated ball. This parameter only
admits positive values greater than 0 (zero).
Dr Distance the probe withdrawals after the first probing movement. Once it
withdraws this distance, it makes a second probing movement. This parameter
only admits positive values greater than 0 (zero).
Rs Calibrated ball radius. See the OEM characteristics to obtain this value.
The cycle verifies the probe adjustment and will display a warning if it detects a
non-adjusted PROBEDELAY value.
The cycles does not verify the probe adjustment.
The points to be measured are on the axes.
The points to be measured are 45º with respect to the axes.
