Automatic block search.
This option recovers the program history up to the block where the previous execution was
canceled. The CNC remembers the block where interruption was canceled, thus not being
necessary to set the stop block. If after the block search, the execution is resumed from that
point, it will do it in the same conditions as if it were executed from the beginning. See
"4.6 Block search." on page 108.
When this option is active, the softkeys that define the execution conditions are applied to
the block search.
Set beginning.
This option sets as starting block for block search the block selected with the cursor. If the
first block is not defined, the block search starts at the first block of the program.
Manual block search.
This option recovers the program history up to a particular block of the program or of the
subroutine, set by the operator. If after the block search, the execution is resumed from that
point, it will do it in the same conditions as if it were executed from the beginning. See
"4.6 Block search." on page 108.
When this option is active, the softkeys that define the execution conditions are applied to
the block search.
Set beginning.
This option sets as starting block for block search the block selected with the cursor. If the
first block is not defined, the block search starts at the first block of the program.
Stop condition.
This option sets the block of the program or of a subroutine where the block search will be
interrupted.
Find text.
This option shows a dialog box for placing the cursor on a particular line of the program or
search for text or a character string in the program.
Go to line.
In this area of the dialog box, the CNC requests the line number to go to. Key in the desired
number and press [ENTER], the cursor will then go to that line.
Find text
In this area of the dialog box, the CNC requests the text to look for. It is also possible to select
whether the search must start at the beginning of the program or at cursor position.
To start the search, press [ENTER] and the cursor will position on the text found. Pressing
[ENTER] again, the CNC will look for the next match and so on. To end the search, press
[ESC]. The cursor will position on the block containing the text searched.
• Select subroutine. This option selects the stop condition in a global subroutine
which has been called upon from the program.
• Set stop block. This option sets as block search interruption block the block
selected with the cursor.
• Number of times. This option sets as stop condition, that the block selected as
the last block has been executed a specific number of times.
If a block containing a multiple machining cycle (·M· model) has
been selected as a stop block, the block search will end just
before the beginning of the nth modal cycle repeated in the
multiple machining.
