Foundry Networks FESX User Manual

Traffic Policies
December 2005 © Foundry Networks, Inc. 15 5
<cir value> is the committed information rate in kbps. This value can be from 64 – 1000000 Kbps.
exceed-action <action> specifies the action to be taken when packets exceed the configured cir value. See
“Specifying the Action to be Taken for Packets that are Over the Limit” .
The count parameter is optional and enables ACL counting. See “ACL and Rate Limit Counting” on page 15-7.
Configuring ACL-Based Adaptive Rate Limiting
Use the procedures in this section to configure ACL-based adaptive rate limiting. Before configuring this feature,
see what to consider in “Configuration Notes and Feature Limitations” on page 15-2.
Table 1 lists the configurable parameters for ACL-based adaptive rate limiting:
If a port receives more than the configured bit or byte rate in a one-second interval, the port will either drop or
forward subsequent data in hardware, depending on the action you specify.
To implement the ACL-based adaptive rate limiting feature, first create a traffic policy then reference the policy in
an extended ACL statement. Lastly, bind the ACL to an interface. Follow the steps below.
1. Create a traffic policy. Enter a command such as the following:
FESX424 Switch(config)# traffic-policy TPDAfour rate-limit adaptive cir 10000
cbs 1600 pir 20000 pbs 4000 exceed-action drop
2. Create a new extended ACL entry or modify an existing extended ACL entry that references the traffic policy.
For example:
FESX424 Switch(config)# access-list 104 permit ip host 210.10.12.2 any traffic-
policy TPDAfour
3. Bind the ACL to an interface.
FESX424 Switch(config)# int e 7
FESX424 Switch(config-if-e7)# ip access-group 104 in
FESX424 Switch(config-if-e7)# exit
The above commands configure an adaptive rate limiting policy that enforces a guaranteed committed rate of
10000 kbps on port e7 and allows bursts of up to 1600 bytes. It also enforces a peak rate of 20000 kbps and
allows bursts of 4000 bytes above the PIR limit. If the port receives additional bits during a given one-second
interval, the port drops all packets on the port until the next one-second interval starts.
Table 1: ACL-Based Adaptive Rate Limiting Parameters
Parameter Definition
Committed Information Rate (CIR) The guaranteed kilobit rate of inbound traffic that is allowed on a port.
Committed Burst Size (CBS) The number of bytes per second allowed in a burst before some
packets will exceed the committed information rate. Larger bursts are
more likely to exceed the rate limit. The CBS must be a value greater
than zero (0). Foundry recommends that this value be equal to or
greater than the size of the largest possible IP packet in a stream.
Peak Information Rate (PIR) The peak maximum kilobit rate for inbound traffic on a port. The PIR
must be equal to or greater than the CIR.
Peak Burst Size (PBS) The number of bytes per second allowed in a burst before all packets
will exceed the peak information rate. The PBS must be a value
greater than zero (0). Foundry recommends that this value be equal
to or greater than the size of the largest possible IP packet in the
stream.
