Foundry Configuration Guide for the FESX, FSX, and FWSX
16 - 74 © Foundry Networks, Inc. December 2005
Displaying IP Information – Layer 2 Switches
You can display the following IP configuration information statistics on Layer 2 Switches:
• Global IP settings – see “Displaying Global IP Configuration Information” on page 16-74.
• ARP entries – see “Displaying ARP Entries” on page 16-75.
• IP traffic statistics – see “Displaying IP Traffic Statistics” on page 16-76.
Displaying Global IP Configuration Information
To display the Layer 2 Switch’s IP address and default gateway, enter the following command from any level of the
CLI:
Syntax: show ip
This display shows the following information.
bad version The number of RIP packets dropped by the device because the RIP
version was either invalid or is not supported by this device.
bad addr family The number of RIP packets dropped because the value in the Address
Family Identifier field of the packet’s header was invalid.
bad req format The number of RIP request packets this router dropped because the
format was bad.
bad metrics This information is used by Foundry customer support.
bad resp format The number of responses to RIP request packets this router dropped
because the format was bad.
resp not from rip port This information is used by Foundry customer support.
resp from loopback The number of RIP responses received from loopback interfaces.
packets rejected This information is used by Foundry customer support.
Table 16.14: CLI Display of IP Traffic Statistics – Layer 3 Switch (Continued)
This Field... Displays...
FESX424 Switch(config)# show ip
Switch IP address: 192.168.1.2
Subnet mask: 255.255.255.0
Default router address: 192.168.1.1
TFTP server address: None
Configuration filename: None
Image filename: None
