Configuring VRRP and VRRPE
December 2005 © Foundry Networks, Inc. 22 - 19
Displaying VRRP and VRRPE Information
You can display the following information for VRRP or VRRPE:
• Summary configuration and status information
• Detailed configuration and status information
• VRRP and VRRPE Statistics
• CPU utilization statistics
Displaying Summary Information
To display summary information for a Layer 3 Switch, enter the following command at any level of the CLI:
Syntax: show ip vrrp brief | ethernet [<slotnum>/]<portnum> | ve <num> | stat
Syntax: show ip vrrp-extended brief | ethernet [<slotnum>/]<portnum> | ve <num> | stat
The brief parameter displays the summary information. If you do not use this parameter, detailed information is
displayed instead. See “Displaying Detailed Information” on page 22-20.
The <slotnum> parameter is required on chassis devices if you specify a port number.
The <portnum> parameter specifies an Ethernet port. If you use this parameter, the command displays VRRP or
VRRPE information only for the specified port.
The ve <num> parameter specifies a virtual interface. If you use this parameter, the command displays VRRP or
VRRPE information only for the specified virtual interface.
The stat parameter displays statistics. See “Displaying Statistics” on page 22-26.
This display shows the following information.
Table 22.3: CLI Display of VRRP or VRRPE Summary Information
This Field... Displays...
Total number of VRRP (or VRRP-
Extended) routers defined
The total number of VRIDs configured on this Layer 3 Switch.
Note: The total applies only to the protocol the Layer 3 Switch is
running. For example, if the Layer 3 Switch is running VRRPE, the
total applies only to VRRPE routers.
Interface The interface on which VRRP or VRRPE is configured. If VRRP or
VRRPE is configured on multiple interfaces, information for each
interface is listed separately.
FastIron SuperX Switch(config-if-e1000-1/6-vrid-1)# show ip vrrp brief
Total number of VRRP routers defined: 1
Interface VRID CurPri P State Master addr Backup addr VIP
1/6 1 255 P Init 192.53.5.1 192.53.5.3 192.53.5.1
This example is for VRRP. Here is an example for VRRPE:
FastIron SuperX Switch(config-if-e1000-1/6-vrid-1)# show ip vrrp-extended brief
Total number of VRRP-Extended routers defined: 1
Interface VRID CurPri P State Master addr Backup addr VIP
1/6 1 255 P Init 192.53.5.2 192.53.5.3 192.53.5.254
