Foundry Networks FESX User Manual

Foundry Configuration Guide for the FESX, FSX, and FWSX
19 - 46 © Foundry Networks, Inc. December 2005
FastIron SuperX Router(config)# router bgp
FastIron SuperX Router(config-router-bsr)# local-as 444
FastIron SuperX Router(config-router-bsr)# neighbor 34.34.34.3 remote-as 333
FastIron SuperX Router(config-router-bsr)# neighbor 34.34.34.3 next-hop-self
FastIron SuperX Router(config-router-bsr)# neighbor 14.14.14.1 remote-as 111
FastIron SuperX Router(config-router-bsr)# neighbor 14.14.14.1 next-hop-self
FastIron SuperX Router(config-router-bsr)# neighbor 24.24.24.2 remote-as 222
FastIron SuperX Router(config-router-bsr)# neighbor 24.24.24.2 next-hop-self
FastIron SuperX Router(config-router-bsr)# neighbor 48.48.48.8 remote-as 888
FastIron SuperX Router(config-router-bsr)# neighbor 48.48.48.8 next-hop-self
FastIron SuperX Router(config-router-bsr)# neighbor 134.134.134.13 remote-as 1313
FastIron SuperX Router(config-router-bsr)# neighbor 134.134.134.13 next-hop-self
FastIron SuperX Router(config-router-bsr)# redistribute connected
FastIron SuperX Router(config-router-bsr)# write memory
Displaying MSDP Information
You can display the following MSDP information:
• Summary information – the IP addresses of the peers, the state of the Layer 3 Switch’s MSDP session with
each peer, and statistics for Keepalive, Source Active, and Notification messages sent to and received from
each of the peers
• Peer information – the IP address of the peer, along with detailed MSDP and TCP statistics
• Source Active cache entries – the Source Active messages cached by the Layer 3 Switch
Displaying Summary Information
To display summary MSDP information, enter the following command at any level of the CLI:
Syntax: show ip msdp summary
This display shows the following information.
Table 19.2: MSDP Summary Information
This Field... Displays...
Peer Address The IP address of the peer’s interface with the Layer 3 Switch
State The state of the MSDP router’s connection with the peer. The state
can be one of the following:
• CONNECTING – The session is in the active open state.
• ESTABLISHED – The MSDP session is fully up.
• INACTIVE – The session is idle.
• LISTENING – The session is in the passive open state.
FastIron SuperX Router(config-msdp-router)# show ip msdp summary
MSDP Peer Status Summary
KA: Keepalive SA:Source-Active NOT: Notification
Peer Address State KA SA NOT
In Out In Out In Out
206.251.17.30 ESTABLISH 3 3 0 640 0 0
206.251.17.41 ESTABLISH 0 3 651 0 0 0
