Displaying Summary Neighbor Information
To display summary neighbor information, enter a command such as the following at any level of the CLI:
Syntax: show ip bgp neighbors [<ip-addr>] | [route-summary]
This display shows the following information.
Table 21.6: BGP4 Route Summary Information for a Neighbor
This Field... Displays...
IP Address The IP address of the neighbor
Routes Received How many routes the Layer 3 Switch has received from the neighbor
during the current BGP4 session.
• Accepted/Installed – Indicates how many of the received routes
the Layer 3 Switch accepted and installed in the BGP4 route
table.
• Filtered/Kept – Indicates how many routes were filtered out, but
were nonetheless retained in memory for use by the soft
reconfiguration feature.
• Filtered – Indicates how many of the received routes were filtered
out.
Routes Selected as BEST Routes The number of routes that the Layer 3 Switch selected as the best
routes to their destinations.
BEST Routes not Installed in IP
Forwarding Table
The number of routes received from the neighbor that are the best
BGP4 routes to their destinations, but were nonetheless not installed
in the IP route table because the Layer 3 Switch received better routes
from other sources (such as OSPF, RIP, or static IP routes).
FESX424 Router(config-bgp-router)# show ip bgp neighbor 192.168.4.211 routes-
summary
1 IP Address: 192.168.4.211
Routes Accepted/Installed:1, Filtered/Kept:11, Filtered:11
Routes Selected as BEST Routes:1
BEST Routes not Installed in IP Forwarding Table:0
Unreachable Routes (no IGP Route for NEXTHOP):0
History Routes:0
NLRIs Received in Update Message:24, Withdraws:0 (0), Replacements:1
NLRIs Discarded due to
Maximum Prefix Limit:0, AS Loop:0
Invalid Nexthop:0, Invalid Nexthop Address:0.0.0.0
Duplicated Originator_ID:0, Cluster_ID:0
Routes Advertised:0, To be Sent:0, To be Withdrawn:0
NLRIs Sent in Update Message:0, Withdraws:0, Replacements:0
Peer Out of Memory Count for:
Receiving Update Messages:0, Accepting Routes(NLRI):0
