Configuring Virtual LANs (VLANs)
December 2005 © Foundry Networks, Inc. 11 - 59
Displaying VLAN Information
After you configure the VLANs, you can verify the configuration using the following methods.
NOTE: If a VLAN name begins with “GVRP_VLAN_“, the VLAN was created by the GARP VLAN Registration
Protocol (GVRP). If a VLAN name begins with “STATIC_VLAN_“, the VLAN was created by GVRP and then was
converted into a statically configured VLAN.
Displaying System-Wide VLAN Information
Use one of the following methods to display VLAN information for all the VLANs configured on the device.
Enter the following command at any CLI level. This example shows the display for the IP sub-net and IPX network
VLANs configured in the examples in “Configuring an IP Sub-Net VLAN with Dynamic Ports” on page 11-34 and
“Configuring an IPX Network VLAN with Dynamic Ports” on page 11-34.
Syntax: show vlans [<vlan-id> | ethernet [<slotnum>/]<portnum>]
The <vlan-id> parameter specifies a VLAN for which you want to display the configuration information.
The <slotnum> parameter is required on chassis devices.
The <portnum> parameter specifies a port. If you use this parameter, the command lists all the VLAN
memberships for the port.
FastIron SuperX Router(config)# show vlans
Total PORT-VLAN entries: 2
Maximum PORT-VLAN entries: 8
legend: [S=Slot]
PORT-VLAN 1, Name DEFAULT-VLAN, Priority level0, Spanning tree Off
Untagged Ports: (S2) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Untagged Ports: (S2) 17 18 19 20 21 22 23 24
Untagged Ports: (S4) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Untagged Ports: (S4) 17 18 19 20 21 22 23 24
Tagged Ports: None
PORT-VLAN 10, Name IP_VLAN, Priority level0, Spanning tree Off
Untagged Ports: (S1) 1 2 3 4 5 6
Tagged Ports: None
IP-subnet VLAN 1.1.1.0 255.255.255.0, Dynamic port enabled
Name: Mktg-LAN
Static ports: None
Exclude ports: None
Dynamic ports: (S1) 1 2 3 4 5 6
PORT-VLAN 20, Name IPX_VLAN, Priority level0, Spanning tree Off
Untagged Ports: (S2) 1 2 3 4 5 6
Tagged Ports: None
IPX-network VLAN 0000ABCD, frame type ethernet_ii, Dynamic port enabled
Name: Eng-LAN
Static ports: None
Exclude ports: None
Dynamic ports: (S2) 1 2 3 4 5 6
