USING THE WEB MANAGEMENT INTERFACE
NOTE: This procedure applies only to VRRP. You cannot display VRRPE information using the Web
management interface.
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration dialog is displayed.
2. Click on the plus sign next to Monitor in the tree view to display the monitoring options.
3. Click on the plus sign next to VRRP in the tree view to expand the list of VRRP option links.
4. Click on the Virtual Router
link to display the virtual router table or the Interface link to display the VRRP
Interface table. The VRRP Interface table shows a row for each interface on the Layer 3 Switch.
NOTE: If a parameter is not defined or does not apply to this type of entry, the field is blank. For example, if the
entry is for a VRRP Owner, the Backup Priority field does not apply and is blank.
NOTE: It is possible for the statistics display for a Backup to show “Master” in the state field even when you have
not yet configured another VRRP or VRRPE router. When you activate a Backup, if the Backup’s Dead interval
expires before the Backup hears from another VRRP or VRRPE router, the Backup becomes the Master.
rxed vrrp vrid not found error count The number of VRRP or VRRPE packets received by the interface
that contained a VRID that is not configured on this interface.
VRID Statistics
rxed arp packet drop count The number of ARP packets addressed to the VRID that were
dropped.
rxed ip packet drop count The number of IP packets addressed to the VRID that were dropped.
rxed vrrp port mismatch count The number of packets received that did not match the configuration
for the receiving interface.
rxed vrrp ip address mismatch count The number of packets received that did not match the configured IP
addresses.
rxed vrrp hello interval mismatch
count
The number of packets received that did not match the configured
Hello interval.
rxed vrrp priority zero from master
count
The current Master has resigned.
rxed vrrp higher priority count The number of VRRP or VRRPE packets received by the interface
that had a higher backup priority for the VRID than this Layer 3
Switch’s backup priority for the VRID.
transitioned to master state count The number of times this Layer 3 Switch has changed from the
backup state to the master state for the VRID.
transitioned to backup state count The number of times this Layer 3 Switch has changed from the master
state to the backup state for the VRID.
Table 21.5: CLI Display of VRRP or VRRPE Statistics (Continued)
This Field... Displays...
