196
Upgrade and Mai
ntenance Manual
CX2550
M1
Liquid coo
ling
Figure 92: Instal
ling the memory cov
ers
Ê
Install both memory covers over the DIMM channels.
I
Make sure not to damage anything when inst
alling the memory
covers (s
ee arrow).
Figure 93: Instal
ling the riser module (B)
Pos.
Component
1
Power connector for power cable of pump 2
2
Power connector for power cable of pump 1
195
197
