Fujitsu SPARC Enterprise M5000 User Manual

Chapter 6 Storage Devices Replacement 6-25
FIGURE 6-9 shows the location of the tape drive unit and tape drive backplane
(TAPEBP) on the M5000
server.
FIGURE 6-9 M5000 Server Tape Drive Unit and Tape Drive Backplane Locations
Location Number Component
1 Tape drive backplane (TAPEBP)
2 Tape drive unit(TAPEU)
2
1
