Fujitsu SPARC Enterprise M5000

Chapter 12 CPU Module Replacement 12-3
FIGURE 12-2 shows the CPU module location on the M5000 server.
FIGURE 12-2 M5000 Server CPU Module Locations
Location Number Component
1 CPU module (CPUM#0)
2 CPU module (CPUM#1)
3 CPU module (CPUM#2)
4 CPU module (CPUM#3)
1
2
3
4
