4-9
Chapter 4 Connection to the External Devices CO2 Concentration Data Input
Connecting the Capnostat 5
By connecting the Capnostat 5 via Gas Unit I/F (HPD-800/HPD-810), CO
2
concentration measured by mainstream
method can be monitored.
In Case of HPD-800/HCP-810
Connect to the AUX connector of the HS-8000.
Mainstream Method
Capnostat 5 (Philips)
Connecting the Sampling Line (Covidien)
By connecting the FilterLine CO
2
sampling line series using the CO
2
Gas Unit (HCP-800/HCP-810), CO
2
concentration measured by intubation or non-intubation can be monitored.
In Case of HCP-800
Connect to the AUX connector of the HS-8000.
In Case of HCP-810
Connect to the AUX connector of the HS-8000.
Sidestream Method
(Microstream technology developed by Covidien is used.)
